Precision Hydrogen 100 H2 Generator
The Precision Hydrogen generators are designed to provide the gas needed for GC detectors such as FID as well as collision gas for ICP-MS.
Applications: GC & GC-MS
Status Available i
Integrated compressor No
The Precision Hydrogen Trace 500 generator is designed primarily for GC carrier gas use, and can also be used for detectors requiring hydrogen fuel gas such as FID and FPD. One generator is capable of supplying multiple GC instruments.
This generator offers a safe, reliable and convenient solution for those using hydrogen for GC carrier gas, producing the highest purity of hydrogen from the Precision Series by utilizing a Proton Exchange Membrane to create the hydrogen gas from deionized water, as well as Pressure Swing Absorption and molecular sieve technology to remove moisture content down to trace levels. The Precision Hydrogen Trace generators are also suitable for providing collision gas for ICP-MS.
The Precision Hydrogen Trace 500 generator also comes with many highly robust safety features as standard, allowing for peace of mind in the laboratory and a far safer, dependable and more convenient alternative to cylinder gas.
*based on O2 content independently verified by National Physical Laboratory, UK
Gas Type: Hydrogen
Max Gas Flow: 500 *cc/min
Max Output Pressure: 100psi/6.9bar
Max Purity: 99.99999% *
Gas Outlets Fitting: 1 x 1/8” Swagelok compression fitting
Water Purity Requirements: ASTM Type II (<1 µS/cm / >1 MΩ-cm)
Water Consumption: 0.4-1.2 L/Day
Power Consumption: 787 Watts
Voltage: 110 / 230
Frequency: 50 / 60
Current: 10 Amps Max
Heat output: 1000
Max Operating Temp: 35°C / 95°F
Accreditations: CSA, CE, FCC
Size (HxWxD) mm: 406 x 380 x 540 mm
Size (HxWxD) Inches: 16 x 15 x 21.3 inches
Generator Weight: 31.5kg / 69.3lbs
We have 10 Precision Hydrogen Trace 500 generators. The key benefits of deploying them have been high purity H2 Gas, trouble free operation & no breakdown, and excellent support from Peak’s maintenance team.Shantilal Modha
We definitely would recommend Peak Scientific generators to other laboratories. The main reasons for recommendation will be that they are robust, reliable and accurate.Sergiu Rusu
With over 20 years' worth of experience in developing gas generator technology alongside leading instrument manufacturers, we offer reliable laboratory gas solutions to meet your specific needs.
Peak's GC Gas calculator is an easy-to-use online tool that will quickly help you choose the right combination of generators to suit your lab’s needs. By answering a few simple questions, we will calculate the gases, flows and purities required to support your GC applications and recommend a solution that will improve your lab workflow.
