Application Types CAD & ELSD

Part number: 65-0003 (230v)
65-0004 (110v)

Status Available i

Integrated compressor Yes

Solaris Air Compressor for ELSD

Peak Scientific's Solaris Air Compressor generator has been designed to support the Solaris Nitrogen generator for ELSD in labs without an external supply of high quality air. Available in both a 230v and 110v option this unit is suitable for all regions.

A common feature in all of Peak's products is ease of use for laboratory workers, allowing them to concentrate on analysis. This unit has been engineered to limit use of valuable laboratory workspace through its stackable design, the Solaris ELSD nitrogen generator can be stacked on top of the compressor.

Solaris has been developed to provide an on-site gas supply of high purity nitrogen for ELSD (Evaporative Light Scattering Detector) for labs using HPLC (High Performance Liquid Chromatography) or alternatively to supply Compact Mass Spectrometer instruments.

Read more
Request a quote Call (800) 767-6532

Features

  • Stackable with Solaris nitrogen generator for ELSD and Compact Mass Spectrometers
  • Provides air for nitrogen system for labs without an external supply
  • Gas is supplied on demand at the push of a button
  • 12 month comprehensive on-site warranty

Gas

Gas Type: Air

Max Gas Flow: VariousL/min

Max Output Pressure: 120psi/8.3bar

Site & Installation

Gas Outlets Fitting: 1 x 1/4" BSPP

Power Consumption: 1150

Voltage: 230 ± 10% VAC

Frequency: 50 / 60 Hz

Current: 2.8 Amps

Heat output: 2420 (BTU)

Dimensions & weight

Solaris Air Compressor Dimensions

Size (HxWxD) mm: 406 x 416 x 540 mm

Size (HxWxD) Inches: 16 x 16.4 x 21.3 inches

Generator Weight: 42kg / 92.4lbs
